HDY Double track Unloader
Specifications
| Parameter: | External Dimension | Value: | L1600*W1500*H1660mm |
|---|---|---|---|
| Parameter: | Guide Rail | Value: | Special National Standard Frosted Aluminum Profile Guide Rail And Special Thousand-bird Plastic Chain |
| Parameter: | Motor | Value: | 90W Taiwan's Special Right-angle Motor |
| Parameter: | Clamping Structure | Value: | Air Tac Pneumatic Clamping Structure |
| Parameter: | Conveyor | Value: | 0.65 M Long Push Plate Conveyor |
| Parameter: | Magazine Specification | Value: | (W)320*(L)355*(H)570mm |
| Parameter: | PCB Specification | Value: | L330*W250 |
| Parameter: | Directions | Value: | Left To Right |
| Parameter: | Lifting Platform Pitch | Value: | 10, 20, 30, 40, 50 |
| Parameter: | Controller | Value: | Huichuan PLC Programmable Controller |
| Parameter: | Operation Panel | Value: | Joint Display Control Touch Screen For Taiwan |
| Parameter: | Power | Value: | 220V 50HZ |
| Parameter: | Air Source | Value: | 0.4-0.6MPa |
| Parameter: | Components | Value: | Panasonic, Omron Optoelectronics, Mingwei Power Supply, Schneider Relay |
| Highlight | unloader smt line machine,unloader smt pick and place machine,pcb smt line machine |
||
Product Description
SMT PCB Conveyor
The SMT PCB Conveyor is a vital component in Surface Mount Technology (SMT) assembly lines, facilitating the smooth and efficient transfer of printed circuit boards (PCBs) between different stages of the assembly process.
Key Advantages
- Improved Workflow Efficiency: Streamlines the transfer process between assembly stages.
- Minimized Downtime: Engineered for reliability to keep production moving.
- Enhanced Quality Assurance: Ensures consistent handling of delicate PCBs.
- Operator-Friendly Design: Intuitive controls for seamless integration.
Product Attributes
FOB Unit: set
MOQ: 0
FOB Price: 0
Packaging & Delivery: N/A
Technical Specifications
| Parameter | Specification |
|---|---|
| External Dimension | L1600*W1500*H1660mm |
| Guide Rail | Frosted aluminum profile & thousand-bird plastic chain |
| Motor | 90W Taiwan right-angle motor |
| Clamping Structure | Air Tac pneumatic |
| Conveyor | 0.65 M long push plate conveyor |
| Magazine Specification | (W)320*(L)355*(H)570mm |
| PCB Specification | L330*W250 |
| Direction | Left to right |
| Lifting Pitch | 10, 20, 30, 40, 50 |
| Controller | Huichuan PLC |
| Operation Panel | Joint display touch screen |
| Power | 220V 50HZ |
| Air Source | 0.4-0.6MPa |
| Components | Panasonic, Omron, Mingwei, Schneider |
